High-Resolution Optical Inspection System for Hexagonal Flange Bolt Quality Control

Automated Optical Screening Device for Six-Sided Flange Bolts

The state-of-the-art equipment employs a vibratory feeder to sequentially place bolts onto an inspection platform. Utilizing advanced industrial CCD cameras with high resolution, the system captures a 360-degree image of each bolt for comprehensive examination. Leveraging sophisticated image processing algorithms, the device ensures accurate detection of both exterior defects like cracks, scratches, and thread damage, as well as critical dimensional accuracy in terms of diameter, height, and step thickness.

Equipped with precise optical imaging technology and intelligent control systems, the machine guarantees precise measurements and automatic processes, including loading, inspection, sorting, and unloading. It streamlines operations by reducing human intervention, making it adaptable to customer-specific requirements, such as customizing inspection parameters, precision adjustments, or altering feeding methods.
